Newbridge®ND-QC500K is a cost-effective outdoor wireless communication product developed based on the requirements of 4G networks. With a high WiFi wireless rate of up to 300 Mbps, it is capable of meeting the high-speed, stable, secure, and easy Internet access needs of outdoor devices.
It is widely used in the field of Internet of Things (IoT) communications, providing users with wireless long-distance data monitoring, collection, and transmission capabilities.
It supports all-network 4G network access and is equipped with one 10/100M adaptive Ethernet LAN interface for connecting to the internal local area network (LAN) and one 10/100M adaptive Ethernet WAN/LAN conversion interface for wired broadband access.
It supports remote centralized management based on the TR069 protocol centralized management platform, making it easy to monitor device status in large-scale deployments.
Industrial device design, built-in multiple protections such as electrostatic, surge, and fast pulse group, easily adaptable to various harsh environments, ensuring long-term stable and reliable operation.
User-friendly IP65 windproof, rainproof, dustproof, and sun protection design, easily adaptable to various outdoor harsh environments.
Independent wireless router processing chip and 4G processing chip, each performing its own function, dual-channel concurrent operation, ensuring a stable and user-friendly system.
Supports 4G network access for telecom, China Unicom, China Mobile, and radio and television networks, supports APN/VPDN connections.
Supports router mode, AP mode, and 4G LTE wireless access, flexible networking, adaptable to various complex scenarios.
Provides 802.11b/g/n WiFi 300M wireless access, with high-gain antennas, covers up to 30 meters in open spaces without obstruction; also provides 10/100Mbps wired access, capable of handling up to 16 users in standby mode.
Supports WPA/WPA2, SSID hiding, and blacklist, effectively ensuring user data security.
Rich status indication lights, status overview, and easy-to-read log system, easily monitor the device's working status. Built-in traffic statistics and traffic assistant functions allow users to stay informed about their data usage.
Built-in quick setup wizard, no professional knowledge required, easily use 4G LTE to access WiFi for Internet connection.
Customizable deployment based on the TR069 protocol centralized management platform, enabling real-time monitoring of device operation status, suitable for large-scale deployments.
Continuous product updates, feature and performance optimizations to ensure adaptation to various network environments and improve user experience.
Hardware configuration | |
Main chipset | MT7628KN |
Clock Frequency | 575MHz |
Memory | 8MB |
Flash | 2MB |
Wireless Technology | 802.11b/g/n 300Mbps MIMO |
Device interface | WAN/LAN conversion *1 10/100Mbps adaptive Ethernet port LAN *1 10/100Mbps adaptive Ethernet port Nano-SIM card DC power supply interface, suitable for power plug with outer diameter of 5.5mm, inner diameter of 2.1mm, and length of over 9.5mm |
Button | RESET, press and hold for 5 seconds to restore factory settings |
Indicator | PWR、LAN 、WiFi、WAN/LAN、4G/3G |
Antenna | Built-in 2.4G 2dBi FPC antennas *2 Built-in 4G LTE 3dBi steel plate antennas *2 |
Power | DC 12V/1A, positive on the outer side and negative on the inner side. |
Operating/Storage Temperature | -30℃～45℃/-40℃～70℃ |
Operating/Storage Humidity | 5%～95%（Non-condensing） |
Size | 17.3*9*5.7cm |
Weight | 0.17kg |
WiFi Spec | |
Frequency Range | 802.11b/g/n:2.4~2.4835GHz |
Channel | 1、2、3、4、5、6、7、8、9、10、11、12、13 |
Modulation | 802.11b: DSSS (DQPSK, DBPSK, CCK) 802.11g: OFDM (BPSK, QPSK,16-QAM) 802.11n: OFDM (BPSK, QPSK,16-QAM, 64-QAM) |
Transmission Rate | 11b up 11Mbps,11g up 54Mbps,11n up 300Mbps |
Receiver Sensitivity | 11b：≤-90±1.5dBm @1Mbps， ≤-84±1.5dBm @11Mbps 11g：≤-86±1.5dBm @6Mbps， ≤-69±1.5dBm @54Mbps 11n 20MHz：≤-85±1.5dBm @MCS0， ≤-67±1.5dBm @MCS7 11n 40MHz：≤-82±1.5dBm @MCS0， ≤-64±1.5dBm @MCS7 |
Transmit Power | 11b: ≥20±1.5dBm@11Mbps 11g: ≥20dBm±1.5dBm@54Mbps 11n: ≥20dBm±1.5dBm@MCS7 |
4G Spec | |
Network Standard | LTE FDD/TDD |
LTE-FDD | B1/B3/B5/B8(supporting hierarchical reception) |
LTE-TDD | B34/B38/B39/B40/B41 (supporting hierarchical reception) |
Transmission Rate | LTE FDD: Up 150Mbps(DL)/Up 50Mbps(UL) LTE TDD: Up 130Mbps(DL)/Up 30Mbps(UL) |
Transmit Power | Class 3 (23dBm±2dB) LTE FDD Bands Class 3 (23dBm±2dB) LTE TDD Bands |
Receiver Sensitivity | FDD B1: -99dBm (10M) FDD B3: -99dBm (10M) FDD B5: -100dBm (10M) FDD B8: -100dBm (10M) TDD B34: -98dBm (10M) TDD B38: -100dBm (10M) TDD B39: -98dBm (10M) TDD B40: -99dBm (10M) TDD B41: -99dBm (10M) |
Software Functions | |
Working Mode | 4G/Router/AP |
Number of connected users | 16 Peoples |
Management | The English web remote management/ Batch management based on the TR069 centralized management platform." |
Status | -System Status/4G Status/Interface Status -User List -Black List |
Network Configuration | -Network Configuration: Operating Mode (4G/Router/AP)/LAN/WAN -APN Settings |
WiFi Settings | WiFi Switch/WiFi name/Encryption/WiFi password/ Hide WiFi/Wireless protocol/Wireless bandwidth/ Wireless channel/WiFi signal strength |
Flow Assistant | Used/Remaining/This month has been used/Today Has been used/The end of the month/Monthly Package flow/Monthly settlement date/Flow control switch |
System Management | -Managed Password -Local Time -Upgrade/Reset: Reset to defaults/Download backup configuration/Restore backup/Local Upgrade -System Log -Network Detection -Reboot: Reboot immediately/ |
Setup Wizard | System mode-WiFi |
