10M/100M/1000M PoE Switch

FEATURES

16 10/100/1000Mbps PoE ports, 2*10/100/1000Mbps uplink port ，1 1000Mbps SFP S lot

Support IEEE802.3af/at

Support restrain network storm, VLAN function

Support Max Transmission distance up to 100m

All port supported by MDI/MDIX auto flip and self-negotiation

Built-in power supply

Maximum power of single PoE port: 30 W

Whole machine power: 300W

Adopts store-and-forward architecture

Fanless, natural cooling, small,compact and quiet design, suitable for desktop or wall

Support lightning protection 4KV

Newbridge® ND-HPG1621 series PoE switch is designed by NEWBRIDGE for meeting the demand of PoE

power supply. It adopts the latest high-speed Ethernet switching chip and ultra-high backplane bandwidth     design, with extremely fast data processing capability to improve smooth data transmission performance. It  has 16 PoE-powered RJ45 ports, 2 RJ45 uplink ports and one independent SFP expansion slots . All of sixteen RJ45 ports support IEEE 802.3af/at standard , with a maximum power supply of 30W for a single port and

300W for the whole machine, which can automatically detect and identify the powered devices that comply with IEEE 802.3af/at standard and supply power for the priority mechanism through the network cable.

With simple and convenient installation and maintenance means and rich service features, it helps users to build a safe and reliable high-performance network. It is mainly positioned at the core or convergence layer of user networks such as industrial parks, buildings, factories and mines, government agencies, and community  broadband; it can  be widely  used  in  Ethernet access  scenarios such as SMEs,  Internet cafes, hotels, and schools.
