FEATURES
Transmits HDMI video and audio signals up to 50M over a single CAT6 cable；
Support video resolution up to 1920*1080@60Hz
Compliance with HDMI 1.3 standard
Support local loop output
Support USB 1.1 standard
Support POC unilateral power supply
Support HDCP 1.3 -- High-bandwidth digital content protection technology
High compatibility, can auto-match source and display device
Built-in automatic adjustment system, make the image smooth, clear and stable
Easy to install, plug and play ；
Newbridge® The HDMI KVM extender provides extension of HDMI signals long distances over a single UTP cable,it supports high resolution up to 1080p, and support keyboard and mouse. The extender can use for a wide range of applications requiring long distance
transmission of high resolution with high quality by its good stability and powerful security.
Parameter | Description | |
Video | Standards | HDMI 1.3;HDCP1.3 |
Maximum pixel clock | 165MHz | |
Maximum data rate | 6.75Gbps | |
Resolution | 1920X1080@60Hz | |
Connector | HDMI-A | |
Impedance | 100Ω | |
Ethernet | Interface | RJ45 |
Transmission distance | CAT6---50M | |
USB | Interface protocol | USB1.1 |
Interface type | PC: USB-B KVM: USB-A | |
Signal type | Digital signal | |
Other | Power supply | The power adapter: DC 5V/ 1A |
Power dissipation | MAX 3W | |
Temperature | Operating: -5℃ ~ +70℃ | |
Humidity | Operating: 5% ~ 90% | |
The warranty | 1 year free warranty | |
Port name | Description |
HDMI IN/ HDMI OUT | HDMI signal input/output |
UTP | RJ45 network interface |
DC5V | Power adapter socket |
EDID | EDID Copy button, Press 3 seconds, copy EDID from HD OUT display device to system .If HDMI IN interface no display connect, restore default EDID. |
USB | USB signal input |
K/M | Keyboard and mouse interface |
LED indicator | Description |
PWR | System power indicator |
STA | HDMI signal indicator |
